A5A Series
6 Socket MIL-Style with 5 Live Sockets, Polycarbonate Molded Connector, Compatible with CTC Dual Output Vibration and Temperature Triaxial Sensors, Permanent Mount, 250 °F (121 °C) Max Temp
Product Features
- 6 Socket Connection for use with CTC Dual Output Vibration and Temperature Triaxial Sensors
- Designed for a Wide Variety of Industrial Applications
- 316L Stainless Steel Locking Ring for Added Durability and Corrosion Resistance
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 6 Socket MIL-Style |
| Shell Material | Polycarbonate Molded |
| Connector Insert Material | Polycarbonate |
| Rating | IP68 |
| Pin-Out | Socket 1 = Ch. Y (+), Red Socket 2 = Ch. X (+), Green Socket 3 = Ch. Z (+), White Socket 4 = Common (-), Black Socket 5 = Temperature (+), Blue Socket 6 - N/A |
