C359 Series
SKF Microlog Data Collector Compatible 25 Pin Connector, Single Channel Acceleration Input with Additional 3.5 Stereo Plug for Headphones
Product Features
- 25 Pin Connector for Single Channel Input with additional 3.5 Stereo Plug for Headphones
| Specifications | |
|---|---|
| Application | Portable Monitoring |
| Connector Type | 25 Pin Subminiature |
| Shell Material | Thermoplastic |
| Connector Insert Material | Steel |
| Rating | IP66 Rated |
| Pin-Out | Pin 1: Tied to Pin 7 Pin 8: Tied to Pin 18 Pin 20: Common (-) Pin 22: Signal/Power (+) Pin 23: Headphone Signal |
