C380 Series
Switchcraft 3 Socket Connector Wired to CB110 Cable for Komline Temp Cables
Product Features
Designed for Use with Komline Temp Cables
| Specifications | |
|---|---|
| Application | Portable Mount |
| Max Temperature | 250 °F (125 °C) |
| Connector Type | 3 Socket |
| Shell Material | Nickel-Plated Zinc |
| Connector Insert Material | Thermoplastic |
| Pin-Out | Socket 1: Signal (+) Red Socket 2: Empty Socket 3: Common (-) Black |
