C648 Series
SDT Compatible 7 Pin LEMO® Connector for Comparable Cable to SDT FUCABLSPLE7LE7-10, For use with SDT Models RS1, RS2, LUBEsense1, and FLX2
Product Features
- For use with SDT RS1, RS2, LUBEsense1, FLX2
- Comparable to SDT FUCABLSPLE7LE7-10
- Compatible Connector: C648
| Specifications | |
|---|---|
| Application | Portable Monitoring |
| Max Temperature | 392 °F (200 °C) |
| Connector Type | 7 Pin LEMO® Connector |
| Connector Insert Material | PEEK |
| Rating | IP66 Rated |
| Pin-Out | Pin 1 Signal (+) Pin 2 Shield/Drain Pin 3 through Pin 7 Signal (+) |
