C97 Series
Emerson 2130 Compatible, 5 Pin Turck Reverse Keyed Connector, Single Channel Tachometer Input
Product Features
5 pin Turck reverse keyed connector wired for tach input with power output on CSI 2130
| Specifications | |
|---|---|
| Application | Portable Monitoring |
| Connector Type | 5 Pin Turck Reverse Keyed Connector |
| Strain Relief | Heat Shrink |
| Shell Material | Nylon |
| Pin Contact Material | Gold Plated Brass |
| Connector Insert Material | Nickel Plated Brass |
| Rating | IP66 |
| Pin-Out | 1 = Signal (+) 2 = N/A 3 = N/A 4 = Common (-) 5 = Shield/Ground |
