CMX3205
SKF Microlog CMXA Series Compatible, 6 Pin Circular Connector to Two, 6 Socket Connections, Dual Channel Acceleration Input, Channel "1" Yellow, Channel "2" Blue (SKF cross reference part number: CMAC 9020)
| Specification | |
|---|---|
| Jacket Material | Polyurethane |
| Cable Length | 15.5 inches (383.7 mm) |
| Connectors | 6 Pin Lemo Connector to Two 6 Socket Lemo Connectors Pin 1 (+) Tied to Socket 1 - Channel "1" Yellow (+) Pin 4 (+) Tied to Socket 1 - Channel "2" Blue (+) Pin 5 (-) Common Tied to Socket 5 - Channel "1" Yellow and Channel "2" Blue (-) Case Grounded |
| Input | Dual Acceleration |
| Cable Diameter | 0.25 in. (6.35 mm) |
| Max Temperature | 250 °F (121 °C) |
Compatible Data Collectors
- SKF CMXA Series Analyzers
Ratings & Certifications
RoHS
