FD93 Series
3 Channel 90 Degree (Right-Angle) BNC Plug Connector, Polyurethane Molded, 250 °F (121 °C) Max Temp
Product Features
3 Right-Angle BNC Jacks to 1 Multi-Conductor Cable
Polyurethane Molded
- Labelled Y Axis (Red), X Axis (Green), Z Axis (White)
- 250 °F (121 °C) Max Temp
- IP66 Rated
| Specifications | |
|---|---|
| Application | Portable or Permanent Measurements |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | BNC Plug |
| Strain Relief | Polyurethane |
| Shell Material | Brass Shell |
| Connector Insert Material | Beryllium Copper |
| Rating | IP66 |
| Pin-Out | Pin = Signal (+) Case = Common (-) |
