J2AX Series
2 Socket Mini-MIL Connector for CTC Miniature Industrial 2 Pin Accelerometers, Epoxy Backfilled with Polycarbonate Backshell, 250 °F (121 °C) Max Temp
Product Features
Compatible with CTC Mini-Sized Accelerometers & UEB330
For use with CB600 Series Armor Jacketed Cabling
- 2 Socket Connection
- 316L Stainless Steel Locking Ring
- IP66 Rated
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 2 Socket Mini-MIL |
| Shell Material | Epoxy Backfilled with Polycarbonate Backshell |
| Connector Insert Material | Polycarbonate |
| Rating | IP66 |
| Pin-Out | A = Signal (+) CTC Red B = Common (-) CTC Black |
