J4Q Series
4 Socket Mini-MIL Connector, Polycarbonate Molded with Grounded Locking Ring for Class 1, Division 2 Locations, 250 °F (121 °C) Max Temp
Product Features
Grounded Locking Ring for Class 1, Division 2 Locations
- 4 Socket Mini-MIL Connection for use with CTC Triaxial Sensors
- Designed to Withstand a Wide Variety of Industrial Applications
- 316L Stainless Steel Locking Ring for Added Durability & Corrosion Resistance
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 250° F (121° C) |
| Connector Type | 4 Socket Mini-MIL |
| Shell Material | Polycarbonate |
| Connector Insert Material | Polycarbonate |
| Rating | IP66 |
| Pin-Out | Socket A = Ch. Y (+), Red Conductor Socket B = Ch. X (+), Green Conductor Socket C = Ch. Z (+), White Conductor Socket D = Common (-), Black Conductor |
