M4T Series
5 Socket M12, Polycarbonate Molded Connector, for use with LS100-M12A, Permanent Mount, 250 °F (121 °C) Max Temp
Product Features
5 Socket M12 Connection for use with LS100-M12A
- 316L Stainless Steel Locking Ring for Added Durability and Corrosion Resistance
| Specifications | |
|---|---|
| Application | Permanent Measurements |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 5 Socket M12 Connector |
| Shell Material | Polycarbonate Molded |
| Connector Insert Material | Polycarbonate |
| Rating | IP68 |
| Pin-Out | Socket 1 = Supply Voltage (+), Red Socket 2 = Not Used, Green Socket 3 = Common (-), Black Socket 4 = Pulse Out (+), White Socket 5 = Empty Case = Shield/Drain |
