M5B Series
Five Socket M12 Connector For Use With STI CMCP760T and CMCP760TT Triaxial Sensors, Polycarbonate Molded, 250 °F (121 °C) Max Temp
Product Features
- For Use With STI CMCP760T and CMCP760TT Triaxial Sensors
- 316L Stainless Steel Locking Ring for Added Durability and Corrosion Resistance
| Specifications | |
|---|---|
| Application | Permanent Measurements |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 5 Socket M12 Connector |
| Shell Material | Polycarbonate Molded |
| Connector Insert Material | Polycarbonate |
| Rating | IP68 |
| Pin-Out | Socket 1 = Temp (+), Brown Socket 2 = Ch. X (+), White Socket 3 = Ch. Y (+), Blue Socket 4 = Ch. Z (+), Black Socket 5 = Common (-) Red |
