M5E Series
5 Socket M12 Extension Cable Connector for Direct Signal Pass-Through, 4 Live Sockets and Socket 5 Connected to Shield/Drain, Polycarbonate Molded, 250 °F (121 °C) Max Temp
Product Features
M12 Extension Cable Connector for Direct Signal Pass-Through
Compatible with single-axis, dual-output, and triaxial accelerometers with 4- or 5-pin M12 connections
- 5 Socket M12 Connector
- Compatible with C650 on the opposite end of cable
| Specifications | |
|---|---|
| Application | Permanent Measurements |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 5 Socket M12 Connector |
| Shell Material | Polycarbonate Molded |
| Connector Insert Material | Polycarbonate |
| Rating | IP68 |
| Pin-Out | Socket 1 = (+), Red Conductor Socket 2 = (+), Green Conductor Socket 3 = (+), White Conductor Socket 4 = (+), Black Conductor Socket 5: (-) Shield Drain |
