MH214-4A
Multipurpose 2 Rail Magnet Mounting Base with 1/4-28 Blind Tapped Hole and Integral Rotating Mounting Nut, 50 lbs. (23 kg) Pull Strength, 1.4 in. (35.56 mm) OD, 0.75 in. (19.05 mm) Height, Aluminum Wrench For Pole Adjustment Sold Separately
Product Features
MH214-1W Aluminum Allen Wrench for Adjustable Pole Alignment Sold Separately
For High Volume Orders Where 1 Wrench Per Magnet is Not Required
- Rare Earth Magnetic base made from Neodymium material
- Provides accurate, consistent measurement points
| Specifications | |
|---|---|
| Max Temperature | 266 °F (130 °C) |
| Case Material | Stainless Steel |
| Magnet Material | Neodymium Iron Boron |
| Dimensions | 1.40 in. (36 mm) OD, 0.75 in. (19 mm) Height |
| Pull Strength | 50 lbs. (23 kg) |
| Sensor Mounting | 1/4-28 Integral Rotating Mounting Nut |
Chemical Compatibilities for Reference
(Click Here for Full List)- Gasoline - A
- Methanol - A
- Lubricants – A
Compatibility
- Compatible with all sensors with 1/4"-28 mounting studs
- Conversion mounting studs available
