A2V Series
High Temperature 2 Socket MIL-Style, Right Angle, PPS Molded Connector, Permanent Mount, 392 °F (200 °C) Max Temp
Product Features
High Temperature Resistance up to 392 °F (200 °C)
- 2 Socket Connection for use with CTC Standard & Compact Size, Top Exit, Single Axis Sensors
- Designed for a Wide Variety of Industrial Applications
- 316L Stainless Steel Locking Ring for Added Durability & Corrosion Resistance
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 392° F (200° C) |
| Connector Type | 2 Socket MIL-Style PPS Right-Angle |
| Shell Material | Polyphenylene Sulfide (PPS) Molded |
| Connector Insert Material | Polyphenylene Sulfide (PPS) |
| Rating | IP68 |
| Pin-Out | A = Signal (+) B = Common (-) |
