D3Q Series
3 Socket MIL-Spec Connector with Backshell, For Class I, Division 2 Locations, Permanent Mount, 250 °F (121 °C) Max Temp
Product Features
- 3 Socket Connection
- 250 ºF Max Temp
- IP66 Rated
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | 3 Socket MIL-Spec |
| Shell Material | Zinc Alloy |
| Connector Insert Material | Neoprene |
| Rating | IP64 |
| Pin-Out | A = Signal (+) B = Common (-) C = Signal (+) |
