MH141-1A
Multipurpose 2 Rail Magnet Mounting Base with M5 Blind Tapped Hole, 50 lbs. (23 kg) Pull Strength, 1.4 in. (35.56 mm) OD, 0.75 in. (19.05 mm) Height
Product Features
- Durable 303 Stainless Steel case and mounting hole
- High strength Neodymium Iron Boron magnet optimizes pull strength and performance
- 2 rail mounting system allows measurements on flat and curved surfaces
| Specifications | |
|---|---|
| Max Temperature | 266 °F (130 °C) |
| Case Material | 303 Stainless Steel |
| Magnet Material | Neodymium Iron Boron |
| Dimensions | 1.40 in. (36 mm) OD, 0.75 in. (19 mm) Height |
| Pull Strength | 50 lbs. (23 kg) |
| Sensor Mounting | M5 Mounting Hole |
Chemical Compatibilities for Reference
(Click Here for Full List)- Gasoline - A
- Methanol - A
- Lubricants – A
Compatibility
- Compatible with all sensors with M5 x 0.08 mounting holes
- Conversion mounting studs sold separately
