Hazardous-Area Approved DD100180 Series

Intrinsically Safe Eddy Current Driver Compatible with 8 mm Proximity Probe Systems, Voltage Output
A dimension drawing of a CTC PRO Line Hazardous-Area Approved DD100180 proximity probe driver.
Specifications
Temperature Range -49 to 185 °F (-45 to 85 °C)
Enclosure Anodized Aluminum
Probe Connector SecureLock
Power & Output Connector 4 Position Terminal Block & BNC
Input Voltage -17.5 to -30 VDC
Linear Range 10 - 90 mils (0.25 - 2.30 mm)
Nominal Voltage Output -200 mV/mil (-7.87 V/mm)
Built to Order

Optional Regulatory Approvals

US & Canada:
Class I Division 1 Groups A, B, C, D
Class II Division 1 Group E, F, G
Class III
Class I Zone 0 AEx ia IIC
Class I Division 2 Groups A, B, C, D
Class II Division 2 Groups E, F, G
Ex ia IIC Ga
ATEX:
SIRA 16ATEX2084X
Ex ia IIC
International (IECEx):
IECEx CSA 16.0017X
Ex ia IIC
Temperature Codes:
T4 = -45°C to 100°C
T5 = -35°C to 85°C
IECEX Certified CSA Certified ATEX Certified CE Certified UKCA Certified ETL Certified
CSA, ATEX, IECEx Approvals Require Intrinsically Safe Barrier
Driver must be mounted in a NEMA 4x and/or IP6x enclosure
FOR REFERENCE ONLY, PLEASE REFER TO CONTROL DRAWING
