A stainless steel, standard size, top exit TA284 dual output vibration monitoring sensor engraved with the CTC Line logo, part number, serial number, and CE and UKCA certification markings.

TA284

DUAL OUTPUT SENSOR, TEMPERATURE & ACCELERATION, M8X1.25 CAPTIVE BOLT, SIDE EXIT 3 PIN CONNECTOR, 100 MV/G, 10 MV/°C, ±10%
  • 30-900,000 CPM Frequency Response (±3dB)
  • -40 to 250°F (-40 to 121°C) Temperature Range
  • IP68 Sealing
  • High Performance in a Low Cost Sensor
  • Helps to Detect Bearing Defects and Temperature Changes

TA284 TYPICAL FREQUENCY RESPONSE

Frequency Response Image
